Automotive Machine Vision System for Interior Panel Inspection

Small vision system to verify that fasteners were applied on the panels prior to assembly.   Semiautomatic requiring the operator to load the part and press two Opto finger switches for activation of the part into the vision tunnel. Project Photos: [gallery columns="...

Read more...

Plant Engineering E-House Controls & Project Management

E houses shown as the two containers below. Custom Siemen’s control panels and AB MCC’s inside each container. MESH modified the containers with windows, doors, insulation, lighting and wire tray. Containers were repainted with two part Epoxy. Containers were fully wired...

Read more...

Refrigeration Tube Bending Line – Tube Processing Equipment

Two refrigeration tube bending lines for hot gas loops.  Included were the following; MIIC robotic tube benders Hardy tube straighteners Tubing reel unwinder Fanuc controls MESH dimple benders MESH “S” benders MESH fitting feeder Vision inspect...

Read more...

Robotic Machine Assembly for Automotive Tier 1

Flexible assembly cell for heat shield assembly. The cell utilized five bowl feeders for feed and registration of washers, bushings, brackets and fasteners. One Epson 3 axis Scara robot and Two six axis Kuka KR5 robots were utilized for assembly and handling of the heat shie...

Read more...

Automotive Brake Line Feeder & Inspection – Tube Processing

Brake line tube loader. Manual loading of a bundle of tube to the infeed. Machine would collate, escape and feed one tube to the downstream equipment. Vision inspection of tube end for dimensional and inclusion test for tube plugs. Project Photos: ...

Read more...

Lean Cells for Cam Phaser Assembly and Test

Project to supply three lean cell (semiautomatic) that allow the operator to assemble cam phasers. Machines would insert/press filter screens, pins, collars, springs and other components to precise dimensions and forces. 5 ton presses used for the main process. Poke Yoke sys...

Read more...

Robotic Carpet Tile Box Palletizing System

Carpet tile palletizing Cell.   Special custom designed end of arm tool for picking up and supporting a case of carpet squares.   Case had no bottom and needed support. 5 bundles per minute cycle rate Conveyor controls for infeed and outfeed Automatic stretch ...

Read more...

Robotic Machine Tending for Automotive Industry

Flexible machine tending cell for Chrysler eight speed transmissions. Four robots in total handling Sun and Stator gears to and from pallet conveyors to cold forging equipment. Included a MESH custom designed oil removal system for removing any cutting oil from the part. Sys...

Read more...

Specialty Web Converting for Tri-Laminate Inline Cast Film

Special Graphite Film Unwinder (8) Spindles Automatic Zero Speed Splice. Inline Lamination Cast Film In between Two Layers of Graphite Film. Rockwell Controls Integration into Cast Film Line. With powered “S” wraps post and pre turnbars. Pr...
